Detail intruduction
| Technische Daten: | Technical data | 技术参数 | |
| steckverbindersystem | Connector System | 金属插头系统 | ￠6mm |
| Bemessungspannung | Rated voltage | 额定电压 | 1000VDC |
| Bemessungsstrom | Rated current | 额定电流 | 16A/20A/32A/40A |
| Prufspannung | Test voltage | 测试电压 | 4kV(50Hz,1min.) |
| Umgebungstemperaturbereich | Ambient temperature range | 环境温度范围 | -30℃…+50℃ |
| Obere Grenztemperatur | Maximum temperature | 温度上限 | +105℃ |
| Schutzart,gesteckt | Protection rating (Connector Engaged) | 防护等级,插合状态 | Type 3S |
| Ungesteckt | Touch protection rating | 触摸保护 | IP2X |
| Kontaktwiderstand der Steckverbinder | Connector contact resistance | 连接器接触阻抗 | 0.5mΩMax(AC) |
| Schutzklasse | Safety rating | 安全等级 | Ⅱ |
| Kontaktmaterial | Terminal material | 端子材料 | CopperAlloy |
| Isolationsmaterial | Insulation material | 绝缘材料 | PC |
| Verriegelungssystem | Locking system | 锁紧系统 | Snap-in |
| Flammklasse | Flame class | 火焰等级 | UL-94-VO |
| Salznebelsprühtest,Scharfegrad 5 | Level 5 severe salt spray corrosion test | 腐蚀试验等级 | IEC60068-2-52 |
| Insertion/withdrawal force | 插拔力 | 75N Max |
